Part 3 - Silver ring retip
The Complete DaDo Online LWA: Module 1-7
•
4m 58s
Finding the Correct Laser Power:
First, find the appropriate power level on the laser for the material being worked on. [00:45]
Adjusting the Power:
Once the initial power level is found, slightly reduce it to ensure controlled application. [01:02]
Adding Silver Material:
Apply silver to the top of the flattened claw, building up the material. [01:12]
Continue adding silver until the level of the repaired claw matches the other existing claws. [02:08]
Removing Excess Material:
Carefully remove any excess silver that has been added. [02:40]
Working the Silver In:
Manipulate and work the added silver into the claw to create a solid bond. [02:47]
Increasing the Spot Size:
Increase the laser's spot size to blend and smooth the added material. [02:52]
Protecting the Stone:
Use a protective tool, such as a knife blade, to guard the gemstone from accidental laser contact. [03:00]
Shaping the Claw:
Further work the silver into the claw, shaping it to the desired form. [03:24]
Reducing the Spot Size:
Reduce the laser's spot size for finer detail and finishing. [03:46]
Smoothing the Surface:
Smooth the surface of the repaired claw to eliminate any rough edges or imperfections. [04:13]
Rounding and Finishing:
Gently round off the tip of the claw, shaping it to match the other claws and complete the repair. [04:23]
Up Next in The Complete DaDo Online LWA: Module 1-7
-
Introduction to Module 6
In module six, we'll be covering how to repair hollow and costume jewellery, which is more advanced, using the DaDo 2.0 laser welder.
-
Part 1 - Gold hollow earring
Timeline:
Preparation:
Ensure the laser's power is at its lowest setting [00:37].
Use the infill wire as a guard to prevent damage to the hollow earring [00:45].
Attachment:
Use the smallest point setting on the laser [01:06].
Melt the wire onto the earring [00:51].
Infilling:
Work the melted go... -
Part 2 - Silver hollow earring
Timeline:
Power Control:
Begin by ensuring the laser power is not set too high to avoid making a hole in the earring. [00:36]Wire Placement:
Carefully place the laser wire into the split groove of the earring, using the smallest point size on the laser. [00:43]Laser Application:
Activate the...
